The Sick WL280-2P1131 is a compact photoelectric sensor designed for reliable and efficient object detection in industrial environments. This sensor utilises a reflex barrier principle with a dual lens system, ensuring precise detection over a maximum range of 15 metres. The WL280-2P1131 features a visible red LED light source, making alignment straightforward and enhancing operational accuracy. Its robust ABS plastic housing and IP66/IP67 protection ratings provide excellent durability and resistance to harsh conditions, making it suitable for a wide range of applications. The sensor is equipped with a PNP switching output and offers selectable light/dark switching via a rotary switch, providing flexibility in various operational settings. With a fast response time of 0.5 milliseconds and a switching frequency of 1,000 Hz, the WL280-2P1131 is ideal for high-speed applications. Its compact dimensions and versatile mounting options, including a universal mounting bracket and reflector, ensure easy integration into existing systems.
| Specification | Description |
|---|---|
| Part Number | WL280-2P1131 |
| Manufacturer | Sick |
| Product Type | Compact Photoelectric Sensor |
| Dimensions | 23.5 mm x 74.5 mm x 63 mm |
| Housing Material | Plastic, ABS |
| Optical Material | Plastic, PMMA |
| Light Source | LED, visible red light |
| Sensing Range | 0.01 m to 15 m (with Reflector PL80A) |
| Switching Distance | 0.01 m to 12 m (with Reflector P250) |
| Adjustment | Potentiometer for sensing range adjustment |
| Output Type | PNP, light/dark switching selectable |
| Output Current | ≤ 100 mA |
| Response Time | ≤ 0.5 ms |
| Switching Frequency | 1,000 Hz |
| Connection Type | 3-wire cable, 2 m length, PVC material |
| Protection Class | IP66, IP67 |
| Operating Voltage | 10 V DC to 30 V DC |
| Operating Temperature | -25 °C to +55 °C |
| Storage Temperature | -40 °C to +70 °C |
| Weight | 150 g |
| Included Accessories | Mounting bracket BEF-W280, Reflector P250 |
| Description | The Sick WL280-2P1131 is a versatile and compact photoelectric sensor designed for reliable object detection in various industrial applications. With its robust ABS housing and PMMA optics, it ensures durability and precision. The sensor features a visible red LED light source, providing a clear and accurate sensing range of up to 15 meters. It offers easy installation and adjustment with a potentiometer for fine-tuning the sensing range. The WL280-2P1131 supports PNP output with selectable light/dark switching, making it adaptable to different operational requirements. Its high switching frequency and fast response time make it suitable for dynamic environments. The sensor is equipped with a 3-wire PVC cable for secure connections and is rated IP66/IP67 for protection against dust and water ingress. Ideal for use in automation and manufacturing processes, this sensor delivers reliable performance and flexibility. |
